Advantages

1. The ventilator series trolley is mature, and the corresponding trolley can be selected according to the corresponding model.
2. Perfect customized service, professional R&D team can provide solutions according to customized needs.
3. Our “integral” design philosophy always put ergonomic and the integration with medical device in mind.

Specification

Specific Use
Hospital ventilator trolley

Type
Hospital Furniture

Design Style
Modern

Trolley size
Overall Size: φ600*890mm;
Column size: 78*100*810mm
Base size: φ600*70mm
Mounting platform size: 330*250*8mm

Texture
Stainless steel + aluminium alloy

Color
White

Caster
Silent wheels
4 inches*5 pcs (brake)

Capacity
Max. 30kg
Max. push speed 2m/s

Weight
13.2kg

Packing
Carton packing
Dimension: 90*57*21(cm)
Gross weight: 15.8kg

Downloads

Medifocus product catalog-2022

PDF

Accessories

Oxygen cylinder holder

Basket

Humidifier bracket

All Compatible Accessories >

Same Series Products

Medatro^®Medical Trolley B07

VELA ventilator trolley
Mounting platform size: 282*263.5*8mm
Download Specification>>>

Medatro^®Medical Trolley B15

SH200 ventilator trolley
Mounting platform size: Customize
Download Specification>>>

Medatro^®Medical Trolley B20

Bellavista 1000 ventilator trolley
Mounting platform size: 300*230*8mm
Download Specification>>>

Specification

Model name
B07

Specific Use
Hospital ventilator trolley

Type
Hospital Furniture

Trolley size
Overall Size: φ600*890mm;
Column size: 78*100*810mm
Base size: φ600*70mm
Mounting platform size: 282*263.5*8mm

Texture
Stainless steel + aluminium alloy

Color
Blue

Caster
Silent wheels
3 inches*5 pcs (brake+swivel)

Capacity
Max. 30kg
Max. push speed 2m/s

Weight
11.3kg

Packing
Carton packing
Dimension: 90*57*21(cm)
Gross weight: 13.9kg

Specification

Model name
B15

Specific Use
Hospital ventilator trolley

Type
Hospital Furniture

Trolley size
Overall Size: φ600*890mm;
Column size: 78*100*810mm
Base size: φ600*70mm

Texture
Stainless steel + aluminium alloy

Color
White

Caster
Silent wheels
3 inches*5 pcs (brake+swivel)

Capacity
Max. 30kg
Max. push speed 2m/s

Weight
8.2kg

Packing
Carton packing
Dimension: 90*57*21(cm)
Gross weight: 10.8kg

Specification

Model name
B20

Specific Use
Hospital ventilator trolley

Type
Hospital Furniture

Trolley size
Overall Size: φ600*890mm;
Column size: 78*100*810mm
Base size: φ600*70mm
Mounting platform size: 300*230*8mm

Texture
Stainless steel + aluminium alloy

Caster
Silent wheels
3 inches*5 pcs (brake+swivel)

Capacity
Max. 30kg
Max. push speed 2m/s

Weight
14.9kg

Packing
Carton packing
Dimension: 90*57*21(cm)
Gross weight: 17.5kg

Service

Safe stock

Customize

Warranty

Delivery

(Packing) The trolley will be packed with strong carton and protected by inner filled foam to avoid crashing and scratching.
Fumigation-free wooden pallet packing method meets customers’ seaway shipping requirements.

(Delivery) You can choose door to door shipping way, like DHL, FedEx, TNT, UPS or other international expresses to ship samples.
Located in Shunyi Beijing, the factory is only 30km from Beijing Airport and near to Tianjin seaport, makes it very convenient and efficient for batch order shipping, no matter you choose air shipping or sea shipping.

FAQ

Q: Is it easy to install the trolley?
A: Modular design is one of the advantages of the trolleys, satisfied end-user’s quick installation requirement.

Q: What is the MOQ for customized trolley?
A: MOQ is 200 pcs for customized products, welcome to contact us for discussing more details.

Q: How can i clean the trolley?
A: As the trolleys have been done with surface finishing, makes them are very easy to be cleaned, you can wipe them as daily cleanness.

Q: What is the color of trolley?
A: The color of most of trolleys are medical white, RAL9016.

1.  The function, size, appearance, LOGO and other details of the trolley can be customized according to customer requirements.

2. Standard trolleys are in stock, and the minimum order is one piece.

3. Various trolley parts and support arms, wall mounts, and other medical equipment moving and supporting parts are provided for mass production.
